Proprietary Innovation
Next-Generation
Battery Technology
Modular, fully repairable, immersion-cooled BESS designed for longevity, safety, and circular economy principles.
Immersion Cooled — Dielectric Liquid
Cell / Module Array
Individually Replaceable
Architecture
Engineered for Repairability
Each module is a self-contained unit with individual cell access. The weld-free casing opens easily, enabling quick replacement of affected cells and modules. BMS, cooling, and power electronics are all independently serviceable.
System Architecture — Exploded View
The Volador Advantage
Four Core Innovations
Every design decision serves a purpose — serviceability, safety, sustainability, and scale.
Fully Repairable Modular Architecture
Our proprietary weld-free, adhesive-free casing eliminates the need to scrap entire battery packs. Each cell is individually replaceable, reducing lifecycle costs by up to 60% vs conventional BESS. Hot-swappable modules allow capacity changes with zero downtime.
Cell-Level BMS Intelligence
Real-time cell-level monitoring with advanced Battery Management System. Continuous state-of-health, state-of-charge and temperature tracking enables predictive maintenance, maximises usable capacity and extends service life beyond industry norms.
Liquid Immersion Cooling
Dielectric fluid immersion delivers superior thermal management — keeping cells at optimal temperature, preventing thermal runaway, and acting as a fire suppressant simultaneously. Enables safe deployment across high-ambient-temperature environments, high-performance applications, and safety-critical sectors.
Chemistry Agnostic Design
Our platform is versatile across cell chemistries — Li-ion, sodium-ion, LFP, NMC and beyond — as long as they are in cylindrical or prismatic form factors. This gives customers the freedom to choose the chemistry that best suits their application without re-engineering the system.
Process
How It Works
Deploy
Plug-and-play modular units ship pre-assembled. Configure from 25 kWh to 1 MWh+ by stacking modules. On-site assembly available for large-scale projects. Compatible with standard AC/DC coupling and existing inverter platforms.
Monitor
The onboard BMS streams real-time cell-level data to the cloud dashboard. AI-assisted health scoring continuously tracks state-of-health and flags degradation early, enabling proactive maintenance.
Detect & Isolate
When a cell degrades or failure is detected, the affected module shuts down automatically — isolating the issue instantly. Operations continue uninterrupted with zero downtime while the fault is safely contained.
Repair
A technician swaps the faulty cell or module — not the entire pack. The weld-free casing opens easily, the replacement slots in, and the system is back to full capacity.
Technical Data
Key Specifications
| Parameter | Value |
|---|---|
| Capacity Range | 25 kWh – 1 MWh+ per installation |
| Energy Density | 265 Wh/kg |
| Power Density | 1 kW/kg at 4C discharge |
| Cell Chemistry | Li-ion, LFP, NMC, sodium-ion & beyond |
| Cell Form Factor | Cylindrical or prismatic (chemistry agnostic) |
| Cooling Method | Dielectric liquid immersion |
| Cycle Life | 5,000+ full cycles |
| Operating Temperature | -20°C to +60°C ambient |
| Communication | CAN bus, Modbus, RS485, 4G/LTE |
| Scalability | Hot-swap zero-downtime module add |
| IP Rating | IP55 (outdoor rated enclosure) |
| Repairability | Cell or module level |
Why Volador
Volador vs Traditional BESS
| Feature | Volador Energy | Traditional BESS |
|---|---|---|
| Cell-level repairability | ✓ | ✗ |
| Weld-free construction | ✓ | ✗ |
| Hot-swap modules | ✓ | ✗ |
| Immersion cooling | ✓ | Rare |
| Multi-chemistry support | ✓ | Single |
| Multiple safety features | ✓ | Rare |
| LCA / circularity | High | Low |
| Lifecycle cost | ↓ 60% | Baseline |
Innovation & Recognition
Validated by World-Class Institutions
Our technology has been independently validated through global incubators, grant programmes, and enterprise competitions. Patent filings are in progress to protect our proprietary innovations.
- Finalist — UK StartUp Awards, Green Start-Up of the Year 2026
- Finalist — Great British Entrepreneur Awards, Technology & Innovation Start-Up 2024 & 2025
- Innovate UK GBIP Delegations — Singapore, Australia & USA
- Global Corporate Venturing Symposium — London 2025
- Backed by Royal Academy of Engineering, Innovate UK Edge
- Supported by Faraday Institution & University of Cambridge, amongst others
Proprietary Innovation
Proprietary Architecture
Weld-free modular casing with cell-level access — Patent filing in progress
265 Wh/kg
Energy Density
5,000+
Cycle Life
1 kW/kg
Power Density
25–1000+
kWh Range
Ready to Learn More?
Let's Build the Future
Together
Whether you're an investor, systems integrator, or strategic partner — we'd love to show you what's possible.
